ASTM A213 Tube
What is ASTM A213 Alloy Steel Tube
ASTM A213 steel tube covers seamless ferritic and austenitic steel boilers, Boiler tubes, and heat-exchanger tubes for high-temperature services, designated Grades T5, TP304, etc. Grades with the letter H has higher creep-rupture strength compared with grades with no H. ASME SA213 seamless steel tubes are chrome moly Tubes with alloy element of chromium, and molybdenum.
Bestar Steel is one of the leading manufacturers and suppliers of ASTM A213 Low Alloy Steel Tubes of all grades and dimensions. We also keep stock of ASTM A213 seamless tubes of Alloy Steel: T2, T11, T12, T22, T91, and T92 in annealed and pickled, bright annealed, mill finish, and polished conditions according to customer requirements.
ASTM A213 Alloy Steel Tube Chemical Composition(%, max)
| Steel Grade | ASTM A213 boiler steel tube Chemical Composition% | |||||
| C | Si | Mn | P, S Max | Cr | Mo | |
| T2 | 0.10~0.20 | 0.10~0.30 | 0.30~0.61 | 0.025 | 0.50~0.81 | 0.44~0.65 |
| T11 | 0.05~0.15 | 0.50~1.00 | 0.30~0.60 | 0.025 | 1.00~1.50 | 0.44~0.65 |
| T12 | 0.05~0.15 | Max 0.5 | 0.30~0.61 | 0.025 | 0.80~1.25 | 0.44~0.65 |
| T22 | 0.05~0.15 | Max 0.5 | 0.30~0.60 | 0.025 | 1.90~2.60 | 0.87~1.13 |
| T91 | 0.07~0.14 | 0.20~0.50 | 0.30~0.60 | 0.02 | 8.0~9.5 | 0.85~1.05 |
| T92 | 0.07~0.13 | Max 0.5 | 0.30~0.60 | 0.02 | 8.5~9.5 | 0.30~0.60 |
ASTM A213 Alloy Steel Tube Mechanical properties:
| Steel Grade | ASTM A213 Boiler Steel Tube Mechanical Properties | |||
| T. S | Y. P | Elongation | Hardness | |
| T2 | ≥ 415MPa | ≥ 205MPa | ≥ 30% | 163HBW(85HRB) |
| T11 | ≥ 415MPa | ≥ 205MPa | ≥ 30% | 163HBW(85HRB) |
| T12 | ≥ 415MPa | ≥ 220MPa | ≥ 30% | 163HBW(85HRB) |
| T22 | ≥ 415MPa | ≥ 205MPa | ≥ 30% | 163HBW(85HRB) |
| T91 | ≥ 585MPa | ≥ 415MPa | ≥ 20% | 250HBW(25HRB) |
| T92 | ≥ 620MPa | ≥ 440MPa | ≥ 20% | 250HBW(25HRB) |
ASTM A213 Steel Tubes Outside Diameter and Wall Thickness Tolerance
| OD, mm | OD Tolerance |
| < 25.4 | +/- 0.10 |
| 25.4 – <= 38.1 | +/- 0.15 |
| > 38.1 -< 50.8 | +/- 0.20 |
| 50.8 -< 63.5 | +/- 0.25 |
| 63.5 -< 76.2 | +/- 0.30 |
| 76.2 – <= 101.6 | +/- 0.38 |
| > 101.6 – <= 190.5 | +0.38/-0.64 |
| > 190.5 – <= 228.6 | +0.38/-1.14 |
| OD, mm | WT Tolerance |
| <= 38.1 | +20%/-0 |
| > 38.1 | +22%/-0 |
Size Chart of ASTM A213 Boiler Tube
Outside Diameter & Tolerance of ASTM A213 Boiler Tube
| Hot rolled ASTM A213 Boiler Tube | Outside Diameter, mm | Tolerance, mm |
| OD≤101.6 | +0.4/-0.8 | |
| 101.6＜OD≤190.5 | +0.4/-1.2 | |
| 190.5＜OD≤228.6 | +0.4/-1.6 | |
| Cold Drawn ASTM A213 Boiler Tube | Outside Diameter, mm | Tolerance, mm |
| OD＜25.4 | ±0.10 | |
| 25.4≤OD≤38.1 | ±0.15 | |
| 38.1＜OD＜50.8 | ±0.20 | |
| 50.8≤OD＜63.5 | ±0.25 | |
| 63.5≤OD＜76.2 | ±0.30 | |
| 76.2≤OD≤101.6 | ±0.38 | |
| 101.6＜OD≤190.5 | +0.38/-0.64 | |
| 190.5＜OD≤228.6 | +0.38/-1.14 |
Wall thickness & Tolerance of ASTM A213 Boiler Tube
| Hot rolled ASTM A213 Boiler Tube | Outside Diameter, mm | Tolerance, % |
| OD≤101.6, WT≤2.4 | +40/-0 | |
| OD≤101.6, 2.4＜WT≤3.8 | +35/-0 | |
| OD≤101.6, 3.8＜WT≤4.6 | +33/-0 | |
| OD≤101.6, WT>4.6 | +28/-0 | |
| OD>101.6, 2.4＜WT≤3.8 | +35/-0 | |
| OD>101.6, 3.8＜WT≤4.6 | +33/-0 | |
| OD>101.6, WT>4.6 | +28/-0 | |
| Cold Drawn ASTM A213 Boiler Tube | Outside Diameter, mm | Tolerance, % |
| OD≤38.1 | +20/-0 | |
| OD>38.1 | +22/-0 |
Manufacturing Process of ASTM A213 Boiler Steel Tube
We are a professional Boiler And Alloy Tube manufacturer. We provide Boiler And Alloy Tube of different sizes as well as steel pipes and pipe fittings of various specifications.
Our Advantages:
1.China-leading product service provider and exporter of steel pipe
2.Competitive price and quality from our own factory
3.One-stop Resource Integration
4.Passed the ISO9001, CE, SGS certification every year
5.Best service with 24-hour response
6.Flexible payment methods
7.Strong production capacity
8.Fast delivery and standard export packaging
9.OEM/ODM
If you would like to inquire about any steel products, please feel free to contact us:sales@bestartubes.com
